Power Frequency Pure Sine Wave Inverter Features:
l Complete isolation-type inverter technology, noiseless output.
l Adoption of advanced SPWM technology, pure sine wave output.
l Dynamic current loop control technology to ensure inverter reliable operation.
l Wide DC input voltage range.
l Excellent EMC design.
l Low output harmonic distortion (THD≤3%).
l LED indicators for input voltage range, load power range, normal output & failure state.
l Optional energy saving mode.
l Extensive protections: reverse polarity, short-circuit, overload, under/over input voltage, over-temperature, and inverter’s inner fault identification protections.
l Wide working temperature range (industrial level).
l Continuous operation at full power.
Application
○ For desolate area like mountain, island, pasturing area, etc.
○ For transportation system like beacon light, traffic light, street light, etc.
○ For communication system: unattached operation microwave middle station, optical
cable maintenance station, etc.
○ For solar power station, wind-solar power station, park charging station, family
power house, factory power station, etc.
○ For solar building: has good business future.
○ For the new technology application project.
2KVA off grid three phase inverter technical parameters
Type | SHJ-48-2KSZ | SHJ-96-2KSZ | SHJ-110-2KSZ | SHJ-220-2KSZ | |
DC input | Input rated voltage | 48 VDC | 96 VDC | 110 VDC | 220 VDC |
Input rated current | 46A | 23 A | 20A | 10 A | |
Input DC voltage allowing range | 40-62 VDC | 80-124 VDC | 90-140 VDC | 180-280 VDC | |
AC input (AC bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC± 15% VAC | |||
Input rated current | 5A / 3A / 2.9A | ||||
Bypass transfer time | ≤40 ms （4ms optional） | ||||
AC output | Output rated power | 2KVA | |||
Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC，50Hz / 60Hz | ||||
Output rated current | 5A / 3A / 2.9A | ||||
Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 2% | ||||
Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||||
Wave | Pure sine wave (Isolation transformer) | ||||
THD. | ≤3%(Linear load) | ||||
Power factor (PF) | 0.8 | ||||
Overload capacity | 120%,10 minutes | ||||
Over-current capacity | 200%,10 seconds | ||||
Crest factor (CF) | 3:1 | ||||
Inverter efficiency | ＞90% | ||||
Working Environment | Dielectric strength | 1500VAC,1minute | |||
Noise (1m) | ≤50dB | ||||
Ambient temperature | -10℃~+50℃ | ||||
Humidity | 0~90%, No condensation | ||||
Altitude | ＜2000m Higher than 2000m rated power should be reduced | ||||
Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||||
Communication interface | RS485/WIFI/GPRS/Ethernet (optional) | ||||
Pure Sine Wave | Yes | ||||
Equipped With Copper Transformer | Yes | ||||
Solar Charger | Optional | ||||
AC Charger | Optional | ||||
Generator Port | Optional | ||||
Size | 400×660×800 mm | ||||
Weight | 80 kg | ||||
3KVA off grid three phase inverter technical parameters
Type | SHJ-48-3KSZ | SHJ-96-3KSZ | SHJ-110-3KSZ | SHJ-220-3KSZ | |
DC input | Input rated voltage | 48 VDC | 96 VDC | 110 VDC | 220 VDC |
Input rated current | 69.4A | 34.7 A | 30.3A | 15 A | |
Input DC voltage allowing range | 40-62 VDC | 80-124 VDC | 90-140 VDC | 180-280 VDC | |
AC input (AC bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC± 15% VAC | |||
Input rated current | 8A / 4.5A / 4.3A | ||||
Bypass transfer time | ≤40 ms （4ms optional） | ||||
AC output | Output rated power | 3KVA | |||
Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC，50Hz / 60Hz | ||||
Output rated current | 8A / 4.5A / 4.3A | ||||
Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 2% | ||||
Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||||
Wave | Pure sine wave (Isolation transformer) | ||||
THD. | ≤3%(Linear load) | ||||
Power factor (PF) | 0.8 | ||||
Overload capacity | 120%,10 minutes | ||||
Over-current capacity | 200%,10 seconds | ||||
Crest factor (CF) | 3:1 | ||||
Inverter efficiency | ＞90% | ||||
Working Environment | Dielectric strength | 1500VAC,1minute | |||
Noise (1m) | ≤50dB | ||||
Ambient temperature | -10℃~+50℃ | ||||
Humidity | 0~90%, No condensation | ||||
Altitude | ＜2000m Higher than 2000m rated power should be reduced | ||||
Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||||
Communication interface | RS485/WIFI/GPRS/Ethernet (optional) | ||||
Pure Sine Wave | Yes | ||||
Equipped With Copper Transformer | Yes | ||||
Solar Charger | Optional | ||||
AC Charger | Optional | ||||
Generator Port | Optional | ||||
Size | 400×660×800 mm | ||||
Weight | 100 kg | ||||
5KVA off grid three phase inverter technical parameters
Type | SHJ-48-5KSZ | SHJ-96-5KSZ | SHJ-110-5KSZ | SHJ-220-5KSZ | |
DC input | Input rated voltage | 48 VDC | 96 VDC | 110 VDC | 220 VDC |
Input rated current | 115.7 A | 57.9A | 50.5A | 25 A | |
Input DC voltage allowing range | 40-62 VDC | 80-124 VDC | 90-140 VDC | 180-280 VDC | |
AC input (AC bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC± 15% VAC | |||
Input rated current | 15A / 7.5A / 7A | ||||
Bypass transfer time | ≤40 ms（4ms optional） | ||||
AC output | Output rated power | 5KVA | |||
Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC，50Hz / 60Hz | ||||
Output rated current | 15A / 7.5A / 7A | ||||
Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 2% | ||||
Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||||
Wave | Pure sine wave (Isolation transformer) | ||||
THD. | ≤3%(Linear load) | ||||
Power factor (PF) | 0.8 | ||||
Overload capacity | 120%,10 minutes | ||||
Over-current capacity | 200%,10 seconds | ||||
Crest factor (CF) | 3:1 | ||||
Inverter efficiency | ＞90% | ||||
Working Environment | Dielectric strength | 1500VAC,1minute | |||
Noise (1m) | ≤50dB | ||||
Ambient temperature | -10℃~+50℃ | ||||
Humidity | 0~90%, No condensation | ||||
Altitude | ＜3000m Higher than 3000m rated power should be reduced | ||||
Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||||
Communication interface | RS485/WIFI/GPRS/Ethernet (optional) | ||||
Pure Sine Wave | Yes | ||||
Equipped With Copper Transformer | Yes | ||||
Solar Charger | Optional | ||||
AC Charger | Optional | ||||
Generator Port | Optional | ||||
Size | 520*920*1050 mm | ||||
Weight | 135 kg | ||||
10KVA off grid three phase inverter technical parameters
Type | SHJ-48-10KSZ | SHJ-96-10KSZ | SHJ-110-10KSZ | SHJ-220-10KSZ | |
DC input | Input rated voltage | 48 VDC | 96 VDC | 110 VDC | 220 VDC |
Input rated current | 231.5 A | 115.7 A | 101A | 50.5 A | |
Input DC voltage allowing range | 40-62 VDC | 80-124 VDC | 90-140 VDC | 180-280 VDC | |
AC input (AC bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC± 15% VAC | |||
Input rated current | 28A / 15A / 14.5A | ||||
Bypass transfer time | ≤40 ms（4ms optional） | ||||
AC output | Output rated power | 10KVA | |||
Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC，50Hz / 60Hz | ||||
Output rated current | 28A / 15A / 14.5A | ||||
Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 2% | ||||
Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||||
Wave | Pure sine wave (Isolation transformer) | ||||
THD. | |||||
Power factor (PF) | 0.8 | ||||
Overload capacity | 120%,10 minutes | ||||
Over-current capacity | 200%,10 seconds | ||||
Crest factor (CF) | 3:1 | ||||
Inverter efficiency | ＞92% | ||||
Working Environment | Dielectric strength | 1500VAC,1minute | |||
Noise (1m) | ≤50dB | ||||
Ambient temperature | -10℃~+50℃ | ||||
Humidity | 0~90%, No condensation | ||||
Altitude | ＜2000m Higher than 2000m rated power should be reduced | ||||
Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||||
Communication interface | RS485/WIFI/GPRS/Ethernet (optional) | ||||
Pure Sine Wave | Yes | ||||
Equipped With Copper Transformer | Yes | ||||
Solar Charger | Optional | ||||
AC Charger | Optional | ||||
Generator Port | Optional | ||||
Size | 500*950*1100 mm | ||||
Weight | 160kg | ||||
15KVA off grid three phase inverter technical parameters
Type | SHJ-48-15KSZ | SHJ-96-15KSZ | SHJ-110-15KSZ | SHJ-220-15KSZ | |
DC input | Input rated voltage | 48 VDC | 96 VDC | 110 VDC | 220 VDC |
Input rated current | 347 A | 173.6A | 151.5A | 75.8A | |
Input DC voltage allowing range | 40-62 VDC | 80-124 VDC | 90-140 VDC | 180-280 VDC | |
AC input (AC bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC± 15% VAC | |||
Input rated current | 42A / 23A / 21A | ||||
Bypass transfer time | ≤40 ms（4ms optional） | ||||
AC output | Output rated power | 15KVA | |||
Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC，50Hz / 60Hz | ||||
Output rated current | 42A / 23A / 21A | ||||
Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 2% | ||||
Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||||
Wave | Pure sine wave(Isolation transformer) | ||||
THD. | ≤3%(Linear load) | ||||
Power factor (PF) | 0.8 | ||||
Overload capacity | 120%,10 minutes | ||||
Over-current capacity | 200%,10 seconds | ||||
Crest factor (CF) | 3:1 | ||||
Inverter efficiency | ＞92% | ||||
Working Environment | Dielectric strength | 1500VAC,1minute | |||
Noise (1m) | ≤50dB | ||||
Ambient temperature | -10℃~+50℃ | ||||
Humidity | 0~90%,No condensation | ||||
Altitude | ＜2000m Higher than 2000m rated power should be reduced | ||||
Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||||
Communication interface | RS485/WIFI/GPRS/Ethernet (optional) | ||||
Pure Sine Wave | Yes | ||||
Equipped With Copper Transformer | Yes | ||||
Solar Charger | Optional | ||||
AC Charger | Optional | ||||
Generator Port | Optional | ||||
Size | 570*1020*1200 mm | ||||
Weight | 215 kg | ||||
20KVA off grid three phase inverter technical parameters
Type | SHJ-48-20KSZ | SHJ-96-20KSZ | SHJ-110-20KSZ | SHJ-220-20KSZ | |
DC input | Input rated voltage | 48 VDC | 96 VDC | 110 VDC | 220 VDC |
Input rated current | 463A | 231A | 202 A | 101A | |
Input DC voltage allowing range | 40-62 VDC | 80-124 VDC | 90-140 VDC | 180-280 VDC | |
AC input (AC bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC± 15% VAC | |||
Input rated current | 55.5A / 30A / 29A | ||||
Bypass transfer time | ≤40 ms（4ms optional） | ||||
AC output | Output rated power | 20KVA | |||
Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC，50Hz / 60Hz | ||||
Output rated current | 55.5A / 30A / 29A | ||||
Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 2% | ||||
Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||||
Wave | Pure sine wave (Isolation transformer) | ||||
THD. | ≤3%(Linear load) | ||||
Power factor (PF) | 0.8 | ||||
Overload capacity | 120%,10 minutes | ||||
Over-current capacity | 200%,10 seconds | ||||
Crest factor (CF) | 3:1 | ||||
Inverter efficiency | ＞92% | ||||
Working Environment | Dielectric strength | 1500VAC,1minute | |||
Noise (1m) | ≤50dB | ||||
Ambient temperature | -10℃~+50℃ | ||||
Humidity | 0~90%, No condensation | ||||
Altitude | ＜2000m Higher than 2000m rated power should be reduced | ||||
Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||||
Communication interface | RS485/WIFI/GPRS/Ethernet (optional) | ||||
Pure Sine Wave | Yes | ||||
Equipped With Copper Transformer | Yes | ||||
Solar Charger | Optional | ||||
AC Charger | Optional | ||||
Generator Port | Optional | ||||
Size | 550*1050*1200 mm | ||||
Weight | 220kg | ||||
30KVA off grid three phase inverter technical parameters
Type | SHJ-110-30KSZ | SHJ-220-30KSZ | SHJ-380-30KSZ | |
DC input | Input rated voltage | 110 VDC | 220 VDC | 380 VDC |
Input rated current | 303A | 151 A | 88 A | |
Input DC voltage allowing range | 90-140 VDC | 180-280 VDC | 320-500VDC | |
AC input (AC bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC± 15% VAC | ||
Input rated current | 83A / 45.5A / 43.5 A | |||
Bypass transfer time | ≤40 ms（4ms optional） | |||
AC output | Rated capacity | 30KVA | ||
Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC，50Hz / 60Hz | |||
Output rated current | 83A / 45.5A / 43.5 A | |||
Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 2% | |||
Output frequency accuracy | 50Hz / 60Hz ± 0.05% | |||
Wave | Pure sine wave (Isolation transformer) | |||
THD. | ≤3%(Linear load) | |||
Power factor (PF) | 0.8 | |||
Overload capacity | 120%,10 minutes | |||
Over-current capacity | 200%,10 seconds | |||
Crest factor (CF) | 3:1 | |||
Inverter efficiency | ＞92% | |||
Working Environment | Dielectric strength | 1500VAC,1minute | ||
Noise (1m) | ≤50dB | |||
Ambient temperature | -10℃~+50℃ | |||
Humidity | 0~90%, No condensation | |||
Altitude | ＜2000m Higher than 2000m rated power should be reduced | |||
Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | |||
Communication interface | RS485/WIFI/GPRS/Ethernet (optional) | |||
Pure Sine Wave | Yes | |||
Equipped With Copper Transformer | Yes | |||
Solar Charger | Optional | |||
AC Charger | Optional | |||
Generator Port | Optional | |||
Size | 520*1160*1375mm | |||
Weight | 330 kg | |||
50KVA off grid three phase inverter technical parameters
Type | SHJ-220-50KSZ | SHJ-380-50KSZ | |
DC input | Input rated voltage | 220 VDC | 380 VDC |
Input rated current | 252 A | 146.7A | |
Input DC voltage allowing range | 180-280 VDC | 320-500VDC | |
AC input (AC bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC ± 15% VAC | |
Input rated current | 139A / 76A / 72.5A | ||
Bypass transfer time | ≤100ms（4ms optional） | ||
AC output | Rated capacity | 50KVA | |
Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC，50Hz / 60Hz | ||
Output rated current | 139A / 76A / 72.5A | ||
Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 2% | ||
Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||
Wave | Pure sine wave (Isolation transformer) | ||
THD. | ≤3%(Linear load) | ||
Power factor (PF) | 0.8 | ||
Overload capacity | 120%,10 minutes | ||
Over-current capacity | 200%,10 seconds | ||
Crest factor (CF) | 3:1 | ||
Inverter efficiency | ＞92% | ||
Working Environment | Dielectric strength | 1500VAC,1minute | |
Noise (1m) | ≤50dB | ||
Ambient temperature | -10℃~+50℃ | ||
Humidity | 0~90%, No condensation | ||
Altitude | ＜2000m Higher than 2000m rated power should be reduced | ||
Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||
Communication interface | RS485/WIFI/GPRS/Ethernet (optional) | ||
Pure Sine Wave | Yes | ||
Equipped With Copper Transformer | Yes | ||
Solar Charger | Optional | ||
AC Charger | Optional | ||
Generator Port | Optional | ||
Size | 710*1410*1710 mm | ||
Weight | 505 kg | ||
75KVA off grid three phase inverter technical parameters
Type | SHJ-220-75KSZ | SHJ-380-75KSZ | |
DC input | Input rated voltage | 220 VDC | 380 VDC |
Input rated current | 377.8A | 218.9 A | |
Input DC voltage allowing range | 180-280 VDC | 320-500VDC | |
AC input (AC bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC ± 15% VAC | |
Input rated current | 208A /114A /109A | ||
Bypass transfer time | ≤100ms（4ms optional） | ||
AC output | Rated capacity | 75KVA | |
Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC，50Hz / 60Hz | ||
Output rated current | 208A /114A /109A | ||
Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 2% | ||
Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||
Wave | Pure sine wave (Isolation transformer) | ||
THD. | ≤3%(Linear load) | ||
Power factor (PF) | 0.8 | ||
Overload capacity | 120%,10 minutes | ||
Over-current capacity | 200%,10 seconds | ||
Crest factor (CF) | 3:1 | ||
Inverter efficiency | ＞92% | ||
Working Environment | Dielectric strength | 1500VAC,1minute | |
Noise (1m) | ≤50dB | ||
Ambient temperature | -10℃~+50℃ | ||
Humidity | 0~90%, No condensation | ||
Altitude | ＜2000m Higher than 2000m rated power should be reduced | ||
Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||
Communication interface | RS485/WIFI/GPRS/Ethernet (optional) | ||
Pure Sine Wave | Yes | ||
Equipped With Copper Transformer | Yes | ||
Solar Charger | Optional | ||
AC Charger | Optional | ||
Generator Port | Optional | ||
Size | 750*1500*1700 mm | ||
Weight | 680kg | ||
100KVA off grid three phase inverter technical parameters
Type | SHJ-220-100KSZ | SHJ-380-100KSZ | |
DC input | Input rated voltage | 220 VDC | 380 VDC |
Input rated current | 505.6 A | 292 A | |
Input DC voltage allowing range | 180-280 VDC | 320-500VDC | |
AC input (AC bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC ± 15% VAC | |
Input rated current | 278A / 152A / 145A | ||
Bypass transfer time | ≤100ms（4ms optional） | ||
AC output | Rated capacity | 100KVA | |
Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC，50Hz / 60Hz | ||
Output rated current | 278A / 152A / 145A | ||
Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 2% | ||
Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||
Wave | Pure sine wave (Isolation transformer) | ||
THD. | ≤3%(Linear load) | ||
Power factor (PF) | 0.8 | ||
Overload capacity | 120%,10 minutes | ||
Over-current capacity | 200%,10 seconds | ||
Crest factor (CF) | 3:1 | ||
Inverter efficiency | ＞95% | ||
Working Environment | Dielectric strength | 1500VAC,1minute | |
Noise (1m) | ≤50dB | ||
Ambient temperature | -10℃~+50℃ | ||
Humidity | 0~90%, No condensation | ||
Altitude | ＜2000m Higher than 2000m rated power should be reduced | ||
Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||
Communication interface | RS485/WIFI/GPRS/Ethernet (optional) | ||
Pure Sine Wave | Yes | ||
Equipped With Copper Transformer | Yes | ||
Solar Charger | Optional | ||
AC Charger | Optional | ||
Generator Port | Optional | ||
Size | 750*1500*1800 mm | ||
Weight | 680 kg | ||
200KVA off grid three phase inverter technical parameters
Type | SHJ-380-200KSZ | SHJ-480-200KSZ | |
DC input | Input rated voltage | 380 VDC | 480 VDC |
Input rated current | 584.4 A | 463.3A | |
Input DC voltage allowing range | 320-500 VDC | 400-620 VDC | |
AC input (AC bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC ± 15% VAC | |
Input rated current | 550A / 300A / 290A | ||
Bypass transfer time | ≤100ms（4ms optional） | ||
AC output | Rated capacity | 200KVA | |
Output rated power | 160KW | ||
Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC，50Hz / 60Hz | ||
Output rated current | 550A / 300A / 290A | ||
Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 2% | ||
Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||
Wave | Pure sine wave (Isolation transformer) | ||
THD. | ≤3%(Linear load) | ||
Power factor (PF) | 0.8 | ||
Overload capacity | 120%,10 minutes | ||
Over-current capacity | 200%,10 seconds | ||
Crest factor (CF) | 3:1 | ||
Inverter efficiency | ＞95% | ||
Working Environment | Dielectric strength | 1500VAC,1minute | |
Noise (1m) | ≤50dB | ||
Ambient temperature | -10℃~+50℃ | ||
Humidity | 0~90%, No condensation | ||
Altitude | ＜2000m Higher than 2000m rated power should be reduced | ||
Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||
Communication interface | RS485/WIFI/GPRS/Ethernet (optional) | ||
Pure Sine Wave | Yes | ||
Equipped With Copper Transformer | Yes | ||
Solar Charger | Optional | ||
AC Charger | Optional | ||
Generator Port | Optional | ||
Size | 1280*2000*2060mm | ||
Weight | 2000 kg | ||
300KVA off grid three phase inverter technical parameters
Type | SHJ-480-300KSZ | |
DC input | Input rated voltage | 480 VDC |
Input rated current | 694.4A | |
Input DC voltage allowing range | 400-620 VDC | |
AC input (AC bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC ± 15% VAC |
Input rated current | ||
Bypass transfer time | ≤100ms（4ms optional） | |
AC output | Rated capacity | 300KVA |
Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC，50Hz / 60Hz | |
Output rated current | 830A / 450A / 430A | |
Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 2% | |
Output frequency accuracy | 50Hz / 60Hz ± 0.05% | |
Wave | Pure sine wave (Isolation transformer) | |
THD. | ≤3%(Linear load) | |
Power factor (PF) | 0.8 | |
Overload capacity | 120%,10 minutes | |
Over-current capacity | 200%,10 seconds | |
Crest factor (CF) | 3:1 | |
Inverter efficiency | ＞96% | |
Working Environment | Dielectric strength | 1500VAC,1分钟minute |
Noise (1m) | ≤50dB | |
Ambient temperature | -10℃~+50℃ | |
Humidity | 0~90%, No condensation | |
Altitude | ＜2000m Higher than 2000m rated power should be reduced | |
Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | |
Communication interface | RS485/WIFI/GPRS/Ethernet (optional) | |
Pure Sine Wave | Yes | |
Equipped With Copper Transformer | Yes | |
Solar Charger | Optional | |
AC Charger | Optional | |
Generator Port | Optional | |
Size | 1280*2000*2060mm | |
Weight | 2500 kg | |
500KVA off grid three phase inverter technical parameters
Type | SHJ-480-500KSZ | |
DC input | Input rated voltage | 480 VDC |
Input rated current | 1157A | |
Input DC voltage allowing range | 400-620 VDC | |
AC input (AC bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC ± 15% VAC |
Input rated current | 1380A / 760A / 725A | |
Bypass transfer time | ≤100ms（4ms optional） | |
AC output | Rated capacity | 500KVA |
Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC，50Hz / 60Hz | |
Output rated current | 1380A / 760A / 725A | |
Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 2% | |
Output frequency accuracy | 50Hz / 60Hz ± 0.05% | |
Wave | Pure sine wave (Isolation transformer) | |
THD. | ≤3%(Linear load) | |
Power factor (PF) | 0.8 | |
Overload capacity | 120%,10 minutes | |
Over-current capacity | 200%,10 seconds | |
Crest factor (CF) | 3:1 | |
Inverter efficiency | ＞96% | |
Working Environment | Dielectric strength | 1500VAC,1minute |
Noise (1m) | ≤50dB | |
Ambient temperature | -10℃~+50℃ | |
Humidity | 0~90%, No condensation | |
Altitude | ＜2000m Higher than 2000m rated power should be reduced | |
Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | |
Communication interface | RS485/WIFI/GPRS/Ethernet (optional) | |
Pure Sine Wave | Yes | |
Equipped With Copper Transformer | Yes | |
Solar Charger | Optional | |
AC Charger | Optional | |
Generator Port | Optional | |
Size | 2150*1400*2300mm | |
Weight | 2600 kg | |
800KVA off grid three phase inverter technical parameters
Type | SHJ-480-800KSZ | |
DC input | Input rated voltage | 480 VDC |
Input rated current | 1523 A | |
Input DC voltage allowing range | 400-620VDC | |
AC input (AC bypass) | Allow input voltage range | 380 VAC ± 15% VAC |
Input rated current | 969A | |
Bypass transfer time | ≤100ms（4ms optional） | |
AC output | Rated capacity | 800KVA |
Output rated voltage and frequency | 380 VAC ，50Hz / 60Hz | |
Output rated current | 969A | |
Output voltage accuracy | 380 VAC ± 2% | |
Output frequency accuracy | 50Hz / 60Hz ± 0.05% | |
Wave | Pure sine wave (Isolation transformer) | |
THD. | ≤3%(Linear load) | |
Power factor (PF) | 0.8 | |
Overload capacity | 120%,10 minutes | |
Over-current capacity | 200%,10 seconds | |
Crest factor (CF) | 3:1 | |
Inverter efficiency | ＞96% | |
Working Environment | Dielectric strength | 1500VAC,1minute |
Noise (1m) | ≤50dB | |
Ambient temperature | -10℃~+50℃ | |
Humidity | 0~90%, No condensation | |
Altitude | ＜2000m Higher than 2000m rated power should be reduced | |
Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | |
Communication interface | RS485/WIFI/GPRS/Ethernet (optional) | |
Pure Sine Wave | Yes | |
Equipped With Copper Transformer | Yes | |
Solar Charger | Optional | |
AC Charger | Optional | |
Generator Port | Optional | |
Size | 3600×1000×2200mm | |
Weight | 5500 kg | |
Contact: Leo Shen
Tel: 0086-0519-86509386
Email: sales@shj-electronic.com
WhatsApp: +86-13961402785
Skype: leoshen969
Wechat: leo88dn
Website: https://www.shj-electronic.com
