Monitoring distance	Day vision	6km to recognize human, 15km to recognize vehicle
Imaging lens	Focal length	12.5~750mm
	FOV	0.5°~17.8°
	Auto focusing	support
	Fog penetration	Optional
Camera	Sensor type	1/1.8" Progressive Scan CMOS
	Coding mode	H.264/MPEG4/MJPEG
	Video resolution	1080P, CIF, supporting three stream
	Video bit rate	32Kbps~16Mbps
	Video frame rate	1~25F/S(50Hz), 1~30F/S(60Hz)
Pan-tilt	Loading capacity	22kg(top mounted)
	Angle	Pan: 360°continuous rotation; Tilt: -45°~ +45°
	Speed	Pan: 0.01°~12°/s; Tilt: 0.01°~8°/s
	Presets	255, supporting lens zooming and focusing memory
	Auto cruising	8 paths, 10 presets each path
	Anti-lightning	2000V
Built-in Tracker	Update rate	25Hz
	Output lag	<40ms
	Min target contrast	10%
	Tracking velocity	4 pixels/frame
Interface	Power supply interface	DC30V
Interface	Network interface	RJ45
Environment indicators	Working temp	-25ºC~ +55ºC
	Storage temp	-40ºC~ +65ºC
	Protection grade	IP66
Overall unit power	Power supply	DC30V±10%, with AC220V~DC30V/8A power adapter water-proof power adapter
Overall unit power	Power consumption	≤120W
Physical features	Size	590×200×490mm
	Whole weight	40kg
	Installation method	Outdoor pedestal mounting
