MODEL: SHJ-PT500H3028HTIR230R
Key Features
Ø Adopting continuous zooming thermal imaging technology, imaging clearly, can search in large area and recognize objectives in long distance
Ø Infrared detector with high temp sensitivity with min temp resolution of 50mK
Ø Day & night low illuminance 2 megapixels color to black camera , day & night continuous monitoring
Ø MCIC multi-tube core fusion mixed mode light homogenization technology, no speckle and dark ring, high edge definition
Ø Support fog penetration, backlight compensation , multistage wide dynamic
Ø Support auto focusing function , realizing multiple focusing and triggering mode
Ø Support optional thermal imaging camera presetting function, remembering FOV of each preset bit, enhancing working efficiency
Ø 3D locating function, can realize frame selection magnifying function & clicking to center function, reducing operating difficulty , enhancing device usability
Ø External MMA fine adjustment mechanism, no need to disassemble to complete laser alignment adjustment.
Ø Ball-shape design to increase stability and reduce the wind effect
Ø Professionally designed shell, artistic, light, firm anti-high temp, anti-corrosion, water proof, anti-acid rain
Monitoring Distance | Visible light | Day vision 6~8km | ||
Thermal imaging | Target | Human | Vehicle | |
Detect | 6440m | 18400m | ||
Recognize | 2140m | 4600m | ||
Identify | 1070m | 2300m | ||
HD camera lens | Focal length | 12.5~750mm | ||
FOV | 0.6°～35° | |||
Auto focus | Support | |||
Optical Fog Reduction | Support | |||
Video camera
| Sensor type | 1/1.8''Progressive Scan CMOS | ||
Color mode | Integration IR-CUT ICR DDS, Day/night dual mode | |||
Shutter speed | Auto & manual | |||
Camera control | automatic gain control, automatic white balance, manual day/night swift supported | |||
Penetrate fog | On/off optional | |||
Wide Dynamic | On/off optional | |||
backlight compensation | On/off & area optional | |||
Area-of-interest | On/off support, area optional | |||
Post-focus fine tuning | Support, Remote debugging | |||
Noise reduction | 3D digital noise reduction | |||
Coded format | H.265/H.264/MJPEG | |||
Video resolution | 4MP, five stream supported | |||
Video bit rate | 32Kbps~16Mbps | |||
Video frame rate | 50Hz: 50fps (1920×1080, 1280×960, 1280×720); 25fps (1920×1080, 1280×960, 1280×720); 60Hz: 60fps (1920×1080, 1280×960, 1280×720); 30fps (1920×1080, 1280×960, 1280×720); | |||
subtitles | Title, Date, Time | |||
Image adjust | Brightness, Contrast, Saturation, Acutance etc. | |||
Protocol | TCP/IP/ICMP/HTTP/HTTPS/FTP/DHCP/DNS/DDNS/ RTP/RTSP/RTCP/PPPoE/NTP/UPnP/SMTP/SNMP/ IGMP/802.1X/QoS/IPv6/Bonjour | |||
Features | Heartbeat supported, Video cover, password protection, mirror image function | |||
Thermal lens | Focal length | 20~230mm, 11.5x optical zoom | ||
FOV | 2.7°x2.2°~30.4°x24.6° | |||
Lens control | ||||
Detector | Detector type | Uncooled microbolometer focal plane array(Vox) | ||
Resolution | 640×512 | |||
Spectral range | 8～14μm | |||
NETD | ≤50mK@F1.0,300K | |||
Frame frequency | 25Hz | |||
Non uniformity adjustment | Auto/Manual/Background adjust | |||
Image process | DDE, Pseudo-color | |||
Video output | PAL | |||
EO Pantilt | Pan degree | Pan 360° continuously | ||
Tilt degree | -45°~+90° | |||
Pan speed | 0.01°~80°/s | |||
Tilt speed | 0.01°~60°/s | |||
Presets | 2048 points, Support lens zoom, focus presets & function presets | |||
Preset precision | ±0.05° | |||
Auxiliary switch | 2 groups | |||
Auto cruise | 2 line, 64 presets each line | |||
Protocol | Pelco-D, Pelco-P Optional | |||
Communication band rate | 2400/4800/9600/19200 bps Optional | |||
Anti-thunder | Power 4 000V, Video signal 2000V | |||
Gyro | Support | |||
Interface | Power | DC30V | ||
Internet | 1×10Base-T/100Base-TX, RJ45 Interface | |||
Video control | RS485/RS422communication, BNC Video output | |||
Environment Index | Working Temp. | -25℃~+55℃ | ||
Storage Temp. | -40℃~+65℃ | |||
Protection grade | IP66 | |||
Anti-salt-fog | PH Value 6.5~7.2, Spraying 48 hours continuously | |||
Power | Power supply | DC30V, With wide dc power supply | ||
Consumption | ≤180W | |||
